Backfill the Full Hyperliquid OHLCV Archive
Pull the full Hyperliquid OHLCV archive for one market, or fan the same exporter across all discovered markets for one interval, with a resumable multi-process Python exporter.
If you need bucket-level resume control for the full OHLCV archive, the contract is straightforward: request one candle at a time and iterate the bucket-open timestamps yourself.
For most range pulls, use the paginated /v1/candles/range endpoint shown in the CSV and Parquet guides. This guide keeps the one-bucket worker because it gives you explicit resume state, sparse-gap accounting, and high-RPS sharding for very large archive jobs. We show you how to build a resumable Python exporter that discovers the endpoint with the Dwellir CLI, spreads work across multiple worker processes over HTTP/2, respects your plan's request-rate ceiling, skips empty sparse gaps, and merges the results back into one ordered CSV.
The same exporter can run in two modes:
- backfill one market and one interval, such as
BTC1m - discover all currently listed Hyperliquid markets from Dwellir's HyperCore Info endpoint, then run the one-market exporter once per market for a chosen interval
The exporter is designed to sustain close to the Scale plan's 5000 RPS ceiling from a single workstation. On our measurements it sustains around 4500–5000 useful RPS while backfilling one month of 1s data with zero errors.
Copy-Paste Prompt for Your Coding Tool
Paste this into Claude Code, Codex, Cursor, Windsurf, or another coding agent:
Build me a resumable Python script that backfills the full Hyperliquid candle archive from Dwellir for one market and one interval at a time, using a multi-process HTTP/2 client that can sustain several thousand requests per second.
Requirements:
- First check whether the `dwellir` CLI is installed.
- If it is not installed, recommend installing it with one of these options:
- `brew tap dwellir-public/homebrew-tap && brew install dwellir`
- `curl -fsSL https://raw.githubusercontent.com/dwellir-public/cli/main/scripts/install.sh | sh`
- After installation, ask me to authenticate it by running `dwellir auth login`.
- Check authentication with `dwellir auth status`.
- Get an enabled API key with `dwellir keys list --toon`. If there are multiple good candidates, ask me which key to use.
- Discover the Hyperliquid Index and HyperCore Info endpoints with `dwellir endpoints search hyperliquid --ecosystem hyperliquid --network mainnet --key <name> --json`.
- Use the Dwellir Hyperliquid REST candles endpoint at `api-hyperliquid-index.n.dwellir.com`.
- Export one market and one interval at a time.
- Also provide a market-discovery helper for all-market jobs:
- `{"type":"meta"}` for currently listed native perp names
- `{"type":"spotMeta"}` for spot symbols, using canonical names such as `PURR/USDC` and `@INDEX` names for non-canonical pairs
- `{"type":"perpDexs"}` for HIP-3 `prefix:ASSET` symbols
- Show how to iterate the discovered markets and run the one-market exporter for one chosen interval.
- Use `httpx` with `http2=True` (not `requests`). A single Python asyncio process caps around `1000 RPS` regardless of transport; HTTP/2 multi-process is what scales past that.
- Split the time range into N worker processes using `multiprocessing.spawn`. Each worker runs its own asyncio event loop and its own `httpx.AsyncClient(http2=True)` pool.
- Warm separate HTTP/2 connections per worker so they pick up distinct `DWSESSION` cookies from the platform's backend router.
- Within each worker, run many concurrent async tasks that share the worker's HTTP/2 connections; HTTP/2 multiplexing lets one connection carry many in-flight streams.
- Apply a token-bucket rate limiter per worker so the aggregate request rate matches the plan ceiling (Scale: `5000 RPS`, Growth: `500 RPS`, Developer: `100 RPS`, Free: `20 RPS`).
- For the Scale plan, 8 workers is a good default. For Free/Developer/Growth, a single worker is enough.
- Treat the data as sparse: if a bucket returns `404`, count it and skip it rather than fabricating a candle.
- The OHLCV archive starts at `2025-07-27T08:00:00Z`.
- Iterate bucket-open timestamps between a start and end time.
- Support `1s`, `1m`, and `5m`.
- Write per-shard CSVs with columns: `s, i, t, T, o, h, l, c, v, q, n, x`.
- Persist resume state per shard so the export can continue after an interruption.
- Make the resume logic safe if the process stops between writing a CSV row and updating the shard state files.
- Write the shard state files atomically so a partial write does not break the next run.
- Merge the shard outputs back into one CSV sorted by the candle open time `t` when the run completes.
- Show me how to run a short validation window first, then how to run a larger backfill for BTC `1m` and `1s`.What You Will Learn
- discover the Hyperliquid Index endpoint and your API key name with the Dwellir CLI
- confirm the single-candle REST contract before starting a long backfill
- export one market and one interval into a resumable CSV dataset
- discover native perp, spot, and HIP-3 market symbols from the Info endpoint
- fan the same one-market exporter across all discovered markets for one interval
- handle sparse
404buckets without fabricating candles - run a multi-process HTTP/2 exporter that sustains close to
5000 RPS - resume a large archive download after an interruption
Prerequisites
- Python
3.10+ - the
dwellirCLI installed and authenticated httpxwith the HTTP/2 extras installed- a Dwellir API key name you can use with
dwellir endpoints search ... --key <name>
Check your setup:
python --version
dwellir auth status
dwellir keys list --toon
pip install 'httpx[http2]'If you do not have the CLI yet, install it with one of these:
curl -fsSL https://raw.githubusercontent.com/dwellir-public/cli/main/scripts/install.sh | shDiscover the Endpoint and Verify the Contract
Start by listing your available keys, then ask the CLI to inject the key you want into the Hyperliquid endpoint URLs:
dwellir keys list --toon
dwellir endpoints search hyperliquid --ecosystem hyperliquid --network mainnet --key YOUR_KEY_NAME --jsonYou should see:
Hyperliquid Index, with an HTTPS URL like:
https://api-hyperliquid-index.n.dwellir.com/YOUR_API_KEYHyperliquid HyperCore Info, with an HTTPS URL like:
https://api-hyperliquid-mainnet-info.n.dwellir.com/YOUR_API_KEY/infoNow verify the REST contract with a single known candle:
curl "https://api-hyperliquid-index.n.dwellir.com/YOUR_API_KEY/v1/candles?market=BTC&interval=1m&time=2026-03-30T23:00:00Z"You should get one candle back:
{
"s": "BTC",
"i": "1m",
"t": 1774911600000,
"T": 1774911659999,
"o": "66745",
"h": "66746",
"l": "66687",
"c": "66687",
"v": "4.78586",
"q": "319377.831079999604538463",
"n": 256,
"x": true
}Important: this archive worker intentionally uses the single-candle route because it tracks one bucket per resume state. If you want cursor pagination instead of bucket-level resume accounting, use /v1/candles/range as shown in the CSV and Parquet export guides.
Discover Markets for an All-Markets Backfill
The backfill script below accepts one market at a time. For a whole-universe run, discover the market symbols first and then run the one-market exporter once per symbol.
Save this as discover_hyperliquid_markets.py:
import argparse
import json
import subprocess
from typing import Any
import httpx
def dwellir_catalog(key_name: str) -> dict[str, Any]:
try:
raw = subprocess.check_output(
[
"dwellir",
"endpoints",
"search",
"hyperliquid",
"--ecosystem",
"hyperliquid",
"--network",
"mainnet",
"--key",
key_name,
"--json",
],
text=True,
)
except FileNotFoundError as exc:
raise SystemExit("Install the dwellir CLI first, then run `dwellir auth login`.") from exc
return json.loads(raw)
def endpoint_url(catalog: dict[str, Any], endpoint_name: str) -> str:
for item in catalog.get("data", []):
if item.get("name") == endpoint_name:
return item["networks"][0]["nodes"][0]["https"]
raise RuntimeError(f"Could not find endpoint named {endpoint_name!r}")
def post_info(client: httpx.Client, info_url: str, payload: dict[str, Any]) -> Any:
response = client.post(info_url, json=payload)
response.raise_for_status()
return response.json()
def discover_markets(info_url: str) -> list[str]:
with httpx.Client(timeout=30) as client:
meta = post_info(client, info_url, {"type": "meta"})
spot_meta = post_info(client, info_url, {"type": "spotMeta"})
perp_dexs = post_info(client, info_url, {"type": "perpDexs"})
perps = [
asset["name"]
for asset in meta.get("universe", [])
if isinstance(asset, dict) and asset.get("name") and not asset.get("isDelisted")
]
spots = [
pair["name"] if pair.get("isCanonical") else f"@{pair['index']}"
for pair in spot_meta.get("universe", [])
if isinstance(pair, dict) and pair.get("name") and "index" in pair
]
hip3 = []
dex_items = perp_dexs if isinstance(perp_dexs, list) else perp_dexs.get("dexs", [])
for dex in dex_items:
if not isinstance(dex, dict):
continue
for pair in dex.get("assetToStreamingOiCap", []) or []:
if isinstance(pair, list) and pair:
hip3.append(pair[0])
markets = []
seen = set()
for market in perps + spots + hip3:
if market not in seen:
seen.add(market)
markets.append(market)
return markets
def main() -> None:
parser = argparse.ArgumentParser()
parser.add_argument("--key-name", required=True, help="Dwellir key name from `dwellir keys list --toon`")
parser.add_argument("--output", default="-", help="Market list output path, or - for stdout")
args = parser.parse_args()
catalog = dwellir_catalog(args.key_name)
info_url = endpoint_url(catalog, "Hyperliquid HyperCore Info")
markets = discover_markets(info_url)
if args.output == "-":
for market in markets:
print(market)
return
with open(args.output, "w", encoding="utf-8") as handle:
for market in markets:
handle.write(f"{market}\n")
print(f"wrote {len(markets)} markets to {args.output}")
if __name__ == "__main__":
main()Install the dependency and write the discovered market list:
pip install 'httpx[http2]'
python discover_hyperliquid_markets.py --key-name YOUR_KEY_NAME --output hyperliquid-markets.txt
head hyperliquid-markets.txtThe Info endpoint discovers currently listed markets. Historical OHLCV can include markets that are no longer listed; use the dashboard export catalog when you need Dwellir's full indexed catalog including retired symbols.
Why Multi-Process + HTTP/2
A single Python asyncio process backfilling this endpoint caps at around 1000 useful RPS, regardless of whether you use requests, aiohttp, or httpx. That cap is a per-process ceiling — not an endpoint throttle, not an RTT bound, not a per-source-IP throttle.
Running the same workload across several processes scales past that cap. On the same workstation:
1process: about1000–1300RPS8processes: about5500RPS aggregate12processes: about5400RPS aggregate (diminishing returns above8)
HTTP/2 matters too. In an apples-to-apples test of 8 parallel processes, httpx with http2=True sustained about 5500 RPS aggregate, while aiohttp over HTTP/1.1 reached about 3100 and threaded requests over HTTP/1.1 only 2600. HTTP/2 stream multiplexing means each TCP connection can carry many in-flight requests, which is why fewer connections hit higher aggregate throughput.
The exporter below therefore combines both: multiple worker processes, each running httpx with http2=True and discovering its own DWSESSION-pinned connections. That is what lets a single customer machine sit close to the Scale plan's 5000 RPS ceiling.
Use a Small Pool of Sticky HTTP/2 Connections Per Worker
Dwellir uses the DWSESSION cookie to keep a client pinned to one backend. That is useful for consistency, but it also means a single long-lived connection can spend an entire archive pull on one backend.
The exporter below takes a middle path:
- it spawns a small number of worker processes
- each worker warms a small pool of
httpx.AsyncClient(http2=True)connections and keeps one per discoveredDWSESSIONbackend when possible - each HTTP/2 connection carries many concurrent streams inside the worker
- each worker gets one contiguous time shard of the archive
- the shard CSVs are merged back into one ordered output file at the end
That keeps connection count low, spreads work across the available backends, and still lets one process sustain close to its per-process ceiling.
Choose the Time Window You Want to Backfill
The exporter in this guide works on one market and one interval at a time.
Use these rules when you pick your window:
- the intended archive floor is
2025-07-27T08:00:00Z 1sdata must be aligned to exact seconds1mdata must be aligned to exact minutes5mdata must be aligned to00,05,10, and so on- candles are sparse, so some buckets will return
404and should be skipped 404s are more common on1sthan on1mor5mbut can appear on any interval
For rough planning, 30 days of one market is approximately:
| Interval | Theoretical buckets in 30 days |
|---|---|
1s | 2,592,000 |
1m | 43,200 |
5m | 8,640 |
Build a Resumable Backfill Script
Save this as backfill_hyperliquid_ohlcv.py:
"""Resumable Hyperliquid OHLCV backfill via the Dwellir Hyperliquid Index endpoint.
One market and one interval per run. Splits the time range into N worker
processes, each running an asyncio + HTTP/2 (httpx) loop with sticky-session
discovery for backend pinning. Writes one CSV part per shard plus an atomic
resume state file. Merges parts into one ordered CSV when the run completes.
Usage:
python backfill_hyperliquid_ohlcv.py \\
--api-key $DWELLIR_API_KEY \\
--market BTC --interval 1m \\
--start 2026-03-01T00:00:00Z --end 2026-04-01T00:00:00Z \\
--output btc-1m.csv \\
--rate 5000 --workers 8
Per-plan recommended settings:
Free --rate 20 --workers 1
Developer --rate 100 --workers 1
Growth --rate 500 --workers 1
Scale --rate 5000 --workers 8
"""
from __future__ import annotations
import argparse
import asyncio
import csv
import json
import multiprocessing as mp
import os
import sys
import time
from dataclasses import dataclass
from datetime import datetime, timedelta, timezone
from pathlib import Path
import httpx
ENDPOINT_HOST = "https://api-hyperliquid-index.n.dwellir.com"
ARCHIVE_FLOOR = "2025-07-27T08:00:00Z"
INTERVAL_STEP = {
"1s": timedelta(seconds=1),
"1m": timedelta(minutes=1),
"5m": timedelta(minutes=5),
}
CSV_FIELDS = ["s", "i", "t", "T", "o", "h", "l", "c", "v", "q", "n", "x"]
def parse_utc(value: str) -> datetime:
return datetime.fromisoformat(value.replace("Z", "+00:00")).astimezone(timezone.utc)
def format_utc(value: datetime) -> str:
return value.astimezone(timezone.utc).isoformat().replace("+00:00", "Z")
def split_range(start: datetime, end: datetime, step: timedelta, n_shards: int):
total = max(1, int((end - start) / step))
n_shards = max(1, min(n_shards, total))
base, rem = divmod(total, n_shards)
shards = []
cursor = start
for i in range(n_shards):
size = base + (1 if i < rem else 0)
shard_end = cursor + step * size
if shard_end > end:
shard_end = end
shards.append((cursor, shard_end))
cursor = shard_end
return shards
def atomic_write(path: Path, payload: str):
tmp = path.with_name(path.name + ".tmp")
tmp.write_text(payload)
tmp.replace(path)
def write_state(path: Path, payload: dict):
atomic_write(path, json.dumps(payload, indent=2, sort_keys=True) + "\n")
def load_state(path: Path):
if not path.exists():
return None
try:
return json.loads(path.read_text())
except json.JSONDecodeError:
return None
class TokenBucketAsync:
def __init__(self, rate_per_second: float):
self.rate = float(rate_per_second)
self.capacity = max(self.rate, 1.0)
self.tokens = self.capacity
self.last = time.monotonic()
async def acquire(self):
while True:
now = time.monotonic()
self.tokens = min(self.capacity, self.tokens + (now - self.last) * self.rate)
self.last = now
if self.tokens >= 1.0:
self.tokens -= 1.0
return
await asyncio.sleep((1.0 - self.tokens) / self.rate)
async def warm_clients(base: str, market: str, interval: str, probe_time: datetime,
desired: int, max_attempts: int):
seen = set()
out = []
for _ in range(max_attempts):
if len(out) >= desired:
break
limits = httpx.Limits(max_connections=200, max_keepalive_connections=200)
client = httpx.AsyncClient(http2=True, timeout=30.0, limits=limits)
try:
r = await client.get(
f"{base}/v1/candles",
params={"market": market, "interval": interval, "time": format_utc(probe_time)},
)
except Exception:
await client.aclose()
continue
if r.status_code not in (200, 404):
await client.aclose()
continue
backend = r.cookies.get("DWSESSION") or "unknown"
if backend in seen:
await client.aclose()
continue
seen.add(backend)
out.append((backend, client))
if not out:
out.append(("unknown", httpx.AsyncClient(http2=True, timeout=30.0)))
return out
@dataclass
class ShardResult:
shard_index: int
fetched: int
skipped: int
errors: int
seconds: float
sticky_backends: list
async def shard_worker(shard_index, base, market, interval, shard_start, shard_end,
rate_per_worker, sticky_per_worker, workers_per_client,
csv_path, state_path):
"""Process one time shard with crash-safe resume.
Correctness invariants:
- The state file's `next_time` is always backed by the highest *contiguous*
completed bucket, never just the max in-flight completion. Async tasks
complete out of order, so a max-watermark would skip holes on resume.
- Candles reach the CSV before they are counted in state. Consumers only
append to in-memory buffers; a periodic flusher writes the CSV first,
then updates counters and advances the frontier, then writes state.
- The merge step deduplicates by candle open time `t` to absorb the rare
duplicate that can occur if the process is killed between flushing the
CSV and writing the new state.
"""
step = INTERVAL_STEP[interval]
state = load_state(state_path)
cursor = shard_start
fetched = skipped = errors = 0
if state:
cursor = parse_utc(state["next_time"])
fetched = state.get("fetched", 0)
skipped = state.get("skipped", 0)
errors = state.get("errors", 0)
if cursor >= shard_end:
return ShardResult(shard_index, fetched, skipped, errors, 0.0, [])
clients = await warm_clients(base, market, interval, shard_end - step,
sticky_per_worker, sticky_per_worker * 3)
backends = [b for b, _ in clients]
if not csv_path.exists() or csv_path.stat().st_size == 0:
with csv_path.open("w", newline="") as f:
csv.DictWriter(f, fieldnames=CSV_FIELDS).writeheader()
queue: asyncio.Queue = asyncio.Queue()
cur = cursor
while cur < shard_end:
queue.put_nowait(cur)
cur += step
if queue.qsize() == 0:
for _, c in clients:
await c.aclose()
return ShardResult(shard_index, fetched, skipped, errors, 0.0, backends)
limiter = None if rate_per_worker is None else TokenBucketAsync(float(rate_per_worker))
write_buffer: list = []
completion_buffer: list = [] # (ts, "ok" | "404" | "err")
completed_kind: dict = {} # ts -> kind, for completions past the frontier
counters = {"fetched": fetched, "skipped": skipped, "errors": errors}
frontier = cursor - step # last contiguous-completed bucket
stop_event = asyncio.Event()
def write_checkpoint(*, completed: bool = False) -> None:
write_state(state_path, {
"shard_index": shard_index,
"interval": interval, "market": market,
"next_time": format_utc(shard_end if completed else frontier + step),
"fetched": counters["fetched"],
"skipped": counters["skipped"],
"errors": counters["errors"],
"range_start": format_utc(shard_start),
"range_end": format_utc(shard_end),
**({"completed": True} if completed else {}),
})
def flush_once() -> None:
# Snapshot buffers atomically — these statements have no awaits, so
# asyncio cannot interleave a consumer between the snapshot and the
# clear, and a consumer's two buffer appends always land together.
nonlocal frontier
to_write = write_buffer[:]
write_buffer.clear()
to_complete = completion_buffer[:]
completion_buffer.clear()
if not to_write and not to_complete:
return
# Make candles durable BEFORE counting them — otherwise an interrupt
# between the count and the disk write would silently lose data.
if to_write:
with csv_path.open("a", newline="") as f:
w = csv.DictWriter(f, fieldnames=CSV_FIELDS)
for row in to_write:
w.writerow(row)
# Defer counting until the frontier advances through each timestamp,
# so the persisted counters match exactly what the frontier covers.
# Without this, an interrupt would persist counts for ahead-of-frontier
# completions; resume would re-fetch and double-count them.
for ts, kind in to_complete:
completed_kind[ts] = kind
next_ts = frontier + step
while next_ts in completed_kind:
kind = completed_kind.pop(next_ts)
if kind == "ok":
counters["fetched"] += 1
elif kind == "404":
counters["skipped"] += 1
else:
counters["errors"] += 1
frontier = next_ts
next_ts += step
write_checkpoint()
async def flush_loop():
while not stop_event.is_set():
try:
await asyncio.wait_for(stop_event.wait(), timeout=1.0)
break
except asyncio.TimeoutError:
pass
try:
flush_once()
except Exception:
pass
async def consumer(client):
url = f"{base}/v1/candles"
while True:
try:
ts = queue.get_nowait()
except asyncio.QueueEmpty:
return
if limiter is not None:
await limiter.acquire()
params = {"market": market, "interval": interval, "time": format_utc(ts)}
try:
r = await client.get(url, params=params)
if r.status_code == 200:
try:
candle = r.json()
# These two appends MUST be back-to-back with no await
# between them so the flusher cannot snapshot a CSV
# candle without its matching completion entry.
write_buffer.append(candle)
completion_buffer.append((ts, "ok"))
except Exception:
completion_buffer.append((ts, "err"))
elif r.status_code == 404:
completion_buffer.append((ts, "404"))
else:
completion_buffer.append((ts, "err"))
except Exception:
completion_buffer.append((ts, "err"))
t0 = time.monotonic()
flusher = asyncio.create_task(flush_loop())
tasks = []
for _, c in clients:
for _ in range(workers_per_client):
tasks.append(asyncio.create_task(consumer(c)))
try:
await asyncio.gather(*tasks)
finally:
try:
flush_once()
except Exception:
pass
stop_event.set()
try:
await flusher
except Exception:
pass
for _, c in clients:
try:
await c.aclose()
except Exception:
pass
write_checkpoint(completed=True)
return ShardResult(shard_index, counters["fetched"], counters["skipped"],
counters["errors"], time.monotonic() - t0, backends)
def shard_entry(queue_mp, shard_index, api_key, market, interval, shard_start_iso,
shard_end_iso, rate_per_worker, sticky_per_worker, workers_per_client,
csv_path, state_path):
base = f"{ENDPOINT_HOST}/{api_key}"
try:
result = asyncio.run(shard_worker(
shard_index, base, market, interval,
parse_utc(shard_start_iso), parse_utc(shard_end_iso),
rate_per_worker, sticky_per_worker, workers_per_client,
Path(csv_path), Path(state_path),
))
queue_mp.put(("ok", shard_index, {
"fetched": result.fetched,
"skipped": result.skipped,
"errors": result.errors,
"seconds": result.seconds,
"sticky_backends": result.sticky_backends,
}))
except Exception as exc:
queue_mp.put(("err", shard_index, repr(exc)))
def merge_parts(part_paths, final_output):
"""Merge per-shard CSVs into one file ordered by candle open time `t`.
Shards write rows concurrently so they arrive unsorted. We collect the
combined rows in memory, deduplicate by `t` (the rare duplicate can occur
when a process is killed between flushing the CSV and writing the new
state — the row is durable but the state still asks for it on resume),
and sort before writing the final file. A month of `1s` with ~30%
materialized is roughly 800k rows.
"""
by_t: dict = {}
for p in part_paths:
if not p.exists():
continue
with p.open(newline="") as src:
for row in csv.DictReader(src):
by_t[int(row["t"])] = row
rows = [by_t[k] for k in sorted(by_t)]
tmp = final_output.with_name(final_output.name + ".tmp")
with tmp.open("w", newline="") as out:
w = csv.DictWriter(out, fieldnames=CSV_FIELDS)
w.writeheader()
w.writerows(rows)
tmp.replace(final_output)
def discover_api_key(env_var="DWELLIR_API_KEY", key_name=None):
val = os.environ.get(env_var)
if val:
return val
if not key_name:
raise SystemExit(f"set {env_var} or pass --api-key-name YOUR_KEY_NAME")
import subprocess
try:
out = subprocess.check_output(
[
"dwellir",
"endpoints",
"search",
"hyperliquid",
"--ecosystem",
"hyperliquid",
"--network",
"mainnet",
"--key",
key_name,
"--json",
],
text=True,
)
except (FileNotFoundError, subprocess.CalledProcessError):
raise SystemExit(f"set {env_var} or install/auth the `dwellir` CLI")
catalog = json.loads(out)
for item in catalog.get("data", []):
if item.get("name") == "Hyperliquid Index":
url = item["networks"][0]["nodes"][0]["https"].rstrip("/")
return url.rsplit("/", 1)[-1]
raise SystemExit(f"no Hyperliquid Index endpoint for key '{key_name}'; pass --api-key or set {env_var}")
def main():
parser = argparse.ArgumentParser(
description=__doc__, formatter_class=argparse.RawDescriptionHelpFormatter,
)
parser.add_argument("--api-key", default=None,
help="Dwellir API key UUID; defaults to $DWELLIR_API_KEY or `dwellir endpoints search`")
parser.add_argument("--api-key-name", default=None,
help="key name to resolve via `dwellir endpoints search` if --api-key not given")
parser.add_argument("--market", required=True)
parser.add_argument("--interval", required=True, choices=sorted(INTERVAL_STEP))
parser.add_argument("--start", required=True,
help=f"ISO-8601 UTC start (inclusive); archive floor is {ARCHIVE_FLOOR}")
parser.add_argument("--end", required=True, help="ISO-8601 UTC end (exclusive)")
parser.add_argument("--output", required=True, type=Path)
parser.add_argument("--rate", type=int, default=5000,
help="aggregate request-rate cap (RPS); match your plan ceiling")
parser.add_argument("--workers", type=int, default=8,
help="worker processes (Scale=8, Growth/Developer/Free=1)")
parser.add_argument("--sticky-per-worker", type=int, default=4)
parser.add_argument("--workers-per-client", type=int, default=128)
args = parser.parse_args()
api_key = args.api_key or discover_api_key(key_name=args.api_key_name)
start = parse_utc(args.start)
end = parse_utc(args.end)
step = INTERVAL_STEP[args.interval]
if end <= start:
raise SystemExit("--end must be after --start")
if end > datetime.now(tz=timezone.utc) - step:
raise SystemExit(f"--end must be at most one bucket-step ({step}) before now")
workers = max(1, args.workers)
rate_per_worker = None if args.rate <= 0 else args.rate / workers
shards = split_range(start, end, step, workers)
parts_dir = args.output.with_suffix(args.output.suffix + ".parts")
parts_dir.mkdir(parents=True, exist_ok=True)
print(f"backfill: market={args.market} interval={args.interval} "
f"buckets={int((end - start)/step)} shards={len(shards)} "
f"rate={args.rate} workers={workers}", file=sys.stderr)
ctx = mp.get_context("spawn")
queue_mp = ctx.Queue()
procs = []
csv_paths = []
for i, (s, e) in enumerate(shards):
csv_path = parts_dir / f"shard-{i:03d}.csv"
state_path = parts_dir / f"shard-{i:03d}.state.json"
csv_paths.append(csv_path)
p = ctx.Process(
target=shard_entry,
args=(queue_mp, i, api_key, args.market, args.interval,
format_utc(s), format_utc(e), rate_per_worker,
args.sticky_per_worker, args.workers_per_client,
str(csv_path), str(state_path)),
)
p.start()
procs.append(p)
t0 = time.monotonic()
results = []
failed = []
for _ in range(len(procs)):
tag, sid, payload = queue_mp.get()
if tag == "ok":
results.append((sid, payload))
r = payload
print(f" shard {sid:>3} done: fetched={r['fetched']} skipped={r['skipped']} "
f"errors={r['errors']} {r['seconds']:.1f}s backends={r['sticky_backends']}",
file=sys.stderr)
else:
failed.append((sid, payload))
print(f" shard {sid:>3} ERROR: {payload}", file=sys.stderr)
for p in procs:
p.join(timeout=10.0)
if failed:
print(f"FAILED: {len(failed)} shard(s) errored — partial CSV in {parts_dir}",
file=sys.stderr)
sys.exit(1)
total_fetched = sum(r["fetched"] for _, r in results)
total_skipped = sum(r["skipped"] for _, r in results)
total_errors = sum(r["errors"] for _, r in results)
wall = time.monotonic() - t0
useful = total_fetched + total_skipped
merge_parts(csv_paths, args.output)
print(f"merged {len(csv_paths)} shards -> {args.output}", file=sys.stderr)
print(f"summary: fetched={total_fetched} skipped(404)={total_skipped} "
f"errors={total_errors} wall={wall:.1f}s useful_rps={useful/max(wall,1e-9):.1f}",
file=sys.stderr)
if __name__ == "__main__":
main()This script does six things that matter for fast archive retrieval:
- splits the time range into one contiguous shard per worker process
- warms a small pool of
httpxHTTP/2 connections per worker, keeping one per discoveredDWSESSIONbackend when possible - runs many concurrent async tasks inside each worker, sharing the worker's HTTP/2 connections via stream multiplexing
- treats
404as an empty sparse bucket - keeps one state file per shard so you can resume long runs without replaying the last written candle, with atomic state writes
- merges the shard CSVs back into one output file sorted by candle open time
Run a Short Validation Window First
Before you launch a long archive job, validate the script on a bounded window using a single worker:
python backfill_hyperliquid_ohlcv.py \
--api-key YOUR_API_KEY \
--market BTC --interval 1m \
--start 2026-03-30T22:56:00Z --end 2026-03-30T23:00:00Z \
--output btc-1m-validation.csv \
--rate 500 --workers 1You should see output like:
backfill: market=BTC interval=1m buckets=4 shards=1 rate=500 workers=1
shard 0 done: fetched=4 skipped=0 errors=0 0.3s backends=['juju-...']
merged 1 shards -> btc-1m-validation.csv
summary: fetched=4 skipped(404)=0 errors=0 wall=3.5s useful_rps=1.1The resulting CSV should start like this:
s,i,t,T,o,h,l,c,v,q,n,x
BTC,1m,1774911360000,1774911419999,66737,66738,66731,66735,0.95317,63618.157,103,True
BTC,1m,1774911420000,1774911479999,66735,66748,66724,66747,2.80108,186911.222,130,True
BTC,1m,1774911480000,1774911539999,66748,66755,66747,66754,16.60528,1108386.895,174,TrueBackfill a Larger Archive
Once the validation window looks correct, extend the time range and pick a worker count that matches your plan.
Example: one month of BTC 1m candles on the Scale plan:
python backfill_hyperliquid_ohlcv.py \
--api-key YOUR_API_KEY \
--market BTC --interval 1m \
--start 2026-03-01T00:00:00Z --end 2026-03-31T00:00:00Z \
--output btc-1m-march-2026.csv \
--rate 5000 --workers 8Example: one month of BTC 1s candles on the Scale plan:
python backfill_hyperliquid_ohlcv.py \
--api-key YOUR_API_KEY \
--market BTC --interval 1s \
--start 2026-03-01T00:00:00Z --end 2026-03-31T00:00:00Z \
--output btc-1s-march-2026.csv \
--rate 5000 --workers 8Example: one hour of BTC 1s candles on the Growth plan:
python backfill_hyperliquid_ohlcv.py \
--api-key YOUR_API_KEY \
--market BTC --interval 1s \
--start 2026-03-30T23:00:00Z --end 2026-03-31T00:00:00Z \
--output btc-1s-2026-03-30T23.csv \
--rate 500 --workers 1In a sampled live check against the endpoint, a 1s minute window returned 50 candles and 10 sparse 404 gaps. That is normal. The archive is sparse by design, and 404s count toward your plan rate even though no candle is materialized.
Backfill All Discovered Markets for One Interval
For a whole-universe archive pull, keep the worker focused on one market and wrap it with a market loop. Start with a smoke list so you can verify credentials, output naming, and sparse-market behavior before launching a full run:
set -euo pipefail
head -10 hyperliquid-markets.txt > hyperliquid-markets-smoke.txt
mkdir -p ohlcv-1m-smoke
while IFS= read -r market; do
safe_market=$(printf '%s' "$market" | tr -cs 'A-Za-z0-9_-' '-' | sed 's/^-//; s/-$//')
python backfill_hyperliquid_ohlcv.py \
--api-key YOUR_API_KEY \
--market "$market" --interval 1m \
--start 2025-07-27T08:50:00Z --end 2025-07-27T08:51:00Z \
--output "ohlcv-1m-smoke/${safe_market:-market}-1m.csv" \
--rate 100 --workers 1 || { echo "failed market: $market" >&2; exit 1; }
done < hyperliquid-markets-smoke.txtOnce the smoke run looks correct, use the full discovered list and the production date range you need:
set -euo pipefail
mkdir -p ohlcv-1m
while IFS= read -r market; do
safe_market=$(printf '%s' "$market" | tr -cs 'A-Za-z0-9_-' '-' | sed 's/^-//; s/-$//')
python backfill_hyperliquid_ohlcv.py \
--api-key YOUR_API_KEY \
--market "$market" --interval 1m \
--start 2025-07-27T08:00:00Z --end 2026-04-01T00:00:00Z \
--output "ohlcv-1m/${safe_market:-market}-1m.csv" \
--rate 500 --workers 1 || { echo "failed market: $market" >&2; exit 1; }
done < hyperliquid-markets.txtThis layout produces one CSV per market for a single interval. That is easier to resume, re-run, and convert to partitioned Parquet than appending every market into one long archive file. Increase --rate and --workers only after you confirm the loop works on your plan; every sparse 404 still counts as an API response.
Putting It All Together
The full archival workflow is:
- discover your API key name with
dwellir keys list --toon - confirm the Index and Info endpoints with
dwellir endpoints search hyperliquid --ecosystem hyperliquid --network mainnet --key YOUR_KEY_NAME --json - validate one known candle with
curl - run a short backfill window with
--workers 1 - for all-market jobs, write
hyperliquid-markets.txtwithdiscover_hyperliquid_markets.py - scale one market to
--workers 8 --rate 5000for a Scale-plan run across the full date range, or loop the one-market exporter across your discovered market list - resume from the shard state files in the
.parts/work directory if the job stops midway
When the run is complete, you will have:
- a CSV containing only materialized candles in the public
s i t T o h l c v q n xschema, sorted by candle open time - a
.parts/work directory with one part CSV and one state file per shard - a repeatable pull process for any supported market slug and interval, including an all-markets wrapper for one interval
Rough Extraction Times
For planning purposes, these are good rough estimates for pulling one full market with the multi-process exporter in this guide. Times assume the exporter sustains close to each plan's request-rate ceiling; we measured roughly 4500–5000 useful RPS on the Scale plan from a single workstation with --workers 8.
| Interval | Free 20 RPS | Developer 100 RPS | Growth 500 RPS | Scale 5000 RPS |
|---|---|---|---|---|
5m | about 7 minutes | about 1.5 minutes | about 20 seconds | about 3 seconds |
1m | about 36 minutes | about 7 minutes | about 1.5 minutes | about 10 seconds |
1s | daily cap dominates | about 7 hours | about 1.5 hours | about 10 minutes |
Treat these as rough extraction times, not guarantees. Actual runtime varies with archive sparsity, retry behavior, and the number of backends available behind the endpoint.
For the Free plan, the 100,000 daily response limit dominates once the archive gets large enough. A full month of 1s is roughly 2,600,000 candles, so the daily cap is the real ceiling, not the 20 RPS rate.
Going to Production
For long or repeated archive pulls, tighten the workflow before you automate it:
- keep the API key in an environment variable or secret manager instead of shell history
- split very large jobs into date partitions such as daily or weekly windows
- match
--workersand--rateto your plan:8and5000for Scale,1and your plan's rate for Free/Developer/Growth - write outputs to a durable location before merging them downstream
- treat the CSV as sparse source data and densify later only if your analytics pipeline needs it
- add retry and backoff logic around transient
5xxor network errors if you see a non-zero error count
If you need a typed analytics format after the backfill is complete, convert the CSV to Parquet as a second step instead of changing the retrieval pattern.
Next Steps
- For a simpler flat-file walkthrough, use Export Hyperliquid OHLCV Candles to CSV.
- For a columnar export path, use Export Hyperliquid OHLCV Candles to Parquet.
- For the transport contract itself, see Hyperliquid candles.
